Wing Gate CXT-YW120

Model: CXT-YW120 Specification: 1200*300*1000mm Rod length: 260mm Process: Produced by laser, bending, cutting, welding, polishing, grinding and other processes Material: National standard 304 stainless steel (customizable 201 stainless steel, iron paint) Share to: 0 Material: National standard 304 stainless steel (customizable 201 stainless steel, iron paint)

CXT-YW120 precision brushless wing gate

The innovative universal Pentium series wing gate is a new high-tech channel product that is upgraded to address the defects of the universal series wing gate. The product adopts a new industrial-grade circuit control system and advanced mechanical transmission design, plus accurate and accurate limit technology, which greatly improves the product in terms of performance, stability, environmental protection, life, cost-effectiveness, noise and other aspects.

The Pentium series wing gate has all the functions of the universal series wing gate, and at the same time has its incomparable significant advantages.

Functional description

l It has fault self-check and alarm prompt functions, which is convenient for user maintenance and use.

l It can be connected to any control signal or button or remote control output by any control device to realize single and two-way control of passage.

l Automatic reset function: After each extension of 90 degrees and detecting the passage of people and objects, it will automatically reset, or if it does not pass within the specified time (delay is adjustable in multiple gears), the system will automatically cancel the permission for this passage and return to the initial position.

l Light indication: High-brightness traffic light status indication to guide passage.

l Anti-tailing function:

1. When the person and object in front pass, during the process of swing wing reset, if someone follows or rushes through the gate, an alarm will be sounded.

2. (When equipped with infrared detection) When the person and object in front have not passed completely, if someone follows and breaks in, the infrared alarm will be activated.

3. When someone swipes the card in the forward direction and someone breaks in in the reverse direction, the swing wing will be closed. When the person or object exits, the swing wing will open again to allow forward passage.

l Fire input: can be connected to the fire alarm signal to achieve uninterrupted power supply and normal opening.

l Alarm prompt function: when illegal passage or gate rushing occurs, an alarm prompt will be automatically issued.

l Adjustable speed: the speed of the swing wing opening and closing can be adjusted in 8 levels, and users can set it according to actual needs.

l Automatic protection function: when the external force prevents the normal movement of the swing wing, and the external force is continuous, the system will automatically detect 5 times and then automatically protect and enter the dormant state. When the next legal signal is input, the gate will automatically return to normal.

l Anti-collision buffer function: when illegal passage or forced tailgating occurs, when someone or an object blocks the swing wing, humanized injury prevention is achieved. It also greatly reduces the mechanical damage caused by collision.

l Unmanned duty: the swing wing is automatically opened when the power is off, and automatically resets when the power is on (blocking passage).

l Fast and silent: electric power assistance, zero mechanical wear. About 45-60 people/minute

Expandable functions:

1. Remote control and management through the management computer (command docking is required)

2. Counting function, realize the number of people present, and ensure accurate counting after people pass through.

3. Personalized voice prompt function, making the channel closer to life.

4. Technical parameters

◇ Shell material: SUS304 stainless steel

◇ Model: CXT-YW120

◇ Specification size: 1200×300×1000MM

◇ Weight: about 70KG.

◇ Swing wing type: 260mm (standard) acrylic.

◇ Opening and closing speed: 0.8-2S.

◇ Motor: 24V/30W DC. ( )

◇ Positioning accuracy: 120 degrees photoelectric positioning.

◇ Adaptable temperature: -40℃～ 80℃.

◇ Adaptable humidity: 5%——90%.

◇ Delay reset time: 3S, 5S, 10S, 20S adjustable.

◇ Passing speed: about 45 people/minute.

◇ Shell processing technology: laser, bending, cutting, welding, polishing, grinding and other processes are used for production.

◇ Working environment: indoors and outdoors.
